Products

Visiline 1 Sliding Door


Visiline Sliding Doors
Back To Overview
Colour Finishes
Dual Colour,Colour Powder Coating,Anodized
Thermal Thermal Insulation (in W/m2K)
Uw from 1,2
Sound Sound Reduction (in dB)
40
Product

System for sliding window and doors with straight aesthetic, which counts with a central minimalistic interlock of just 35 mm of visible section.

It allows maximising the glazing capacity up to 34 mm increasing the acoustic and thermal performance.

Its sashes of up to 240 kg weight allow a maximum dimensions of 2200 (W) x 2600 (H) mm.

Technical Specifications


Dimensions (in mm)
Frame construction depth (2 Rails) 70
Frame construction depth (3 Rails) 126
Sash Depth 48
Polyamide Strip Length 34
Profile Thickness Window 1,6
Test Results
Air Permeability Class 4
Water Tightness Class 7A
Wind Resistance Class C5
Opening Possibilities
Sliding Sashes 2,3,4 & 6
Possibility of 3 Rails tick
Maximum Dimensions/sash
Width (in mm) 2200
Height (in mm) 2600
Weight (in Kg) 240
